MJ-LJY vortex water purifier

Product Description
MJ-LJY vortex water purifier is our company’s patented product, which is an advanced water treatment equipment in China, whose features are as follows: it adopts multi chamber design, so the process of water supply and back flush wont affect each other, solving the problem of conventional feed water treatment equipment’s weak point, i.e., stopping supplying water when back flushing. Meantime, back flush tank is not necessary any more, saving construction cost.
By combined application with subsequent processing equipment, it can save the power consumption of two-stage hoisting and reduce the running cost of the system. Meantime, its also suitable for the purification of river water, lake water and coal mine water.
This equipment has obtained three national patents, whose patent numbers are ZL002 19823.1, ZL 01208740.8 and ZL01208442.5 separately.

Main technical parameters:

Model Capacity(m3/h) Dimension(mm) Inlet diameter(mm) Outlet diameter(mm) Operating weight(t) Remark
MJ-LJY-20 20  2000 H5230 65 65 16.2 This data is for reference only , Actual data will be based on water quality.
MJ-LJY-30 30  2400 H5425 80 80 33.7
MJ-LJY-40 40  2800 H5525 80 80 30.3
MJ-LJY-50 50  3000 H5590 80 80 40.1
MJ-LJY-60 60  3400 H5695 100 100 44.9
MJ-LJY-70 70  3600 H5740 100 100 50
MJ-LJY-80 80  3800 H5790 100 100 55.4
MJ-LJY-90 90  4000 H5840 100 100 61.1
MJ-LJY-100 100  4200 H5890 100 100 57
