MG-ZGL automatic valveless filter

Product Description :
MG-ZGL automatic valveless filter is developed on the basis of former sand filter. While strengthening its filtration effect, the automation degree also becomes much higher. Valveless filter doesnt use valves in water inlet, water outlet, flushing and water drainage, running automatically just by water power.
Its characteristics are: low in operation cost, easy in management, safe and reliable in performance. In this equipment, filtration area, distribution water tank, clean water area and back-flushing tank are integrated together, thus it has a compact structure. What the users need to do is just building equipment foundation according to the requirements and connect through inlet and outlet pipes, then the equipment can be put into operation.
Valveless filter takes the capacity of 20t/h as a start up to 500t/h.

Main technical parameters:

Item	Model.	Capacity(m3/h)	Dimension(mm)	Tank No.	Inlet diameter(mm)	Outlet diameter(mm)	Operating weight(t)	Remark
1	MG-ZGL-20	20	Φ1200 H6600	2	65	100	14.5	This data is for reference only , Actual data will be based on water quality.
2	MG-ZGL-30	30	Φ1400 H4400	2	80	125	18.7
3	MG-ZGL-40	40	Φ1600 H4400	2	80	100	23.5
4	MG-ZGL-50	50	Φ1800 H4400	2	80	100	28.9
5	MG-ZGL-60	60	Φ2000 H4400	2	100	150	34.9
6	MG-ZGL-70	70	Φ2200 H4400	2	100	150	41.5
7	MG-ZGL-80	80	Φ2400 H4400	2	100	150	48.7
8	MG-ZGL-90	90	Φ2500 H4400	2	100	150	52.6
9	MG-ZGL-100	100	Φ2600 H4400	2	100	150	56.5
10	MG-ZGL-150	150	Φ3200 H4400	2	150	200	81
11	MG-ZGL-200	200	Φ3600 H4400	2	200	250	107.5
